Raising the Standard of Pool Pumps
The Madimack InverFlow Plus F300i (1.0 HP) sets a new benchmark in pool pump innovation – combining advanced inverter technology, smart Wi-Fi control, and whisper-quiet operation. Powered by InverMAC technology, this compact, high-efficiency DC brushless motor adapts its speed to your pool’s needs, delivering up to 80% energy savings.
Retrofit-ready to replace most major brands without re-plumbing, the F300i simplifies installation and offers advanced features like Skimmer Mode for automatic surface cleaning, Active Energy Monitoring, and 4 programmable timers for daily operation. Built for reliability and backed by Madimack’s industry-first 5-year replacement warranty, it’s the perfect upgrade for a smarter, quieter, and more efficient pool system.
Why Choose the Madimack InverFlow Plus F300i?
InverMAC Technology
Enhanced inverter motor with precise speed control for optimal efficiency and performance.
DC Brushless Motor
Permanent magnetic motor for long lasting energy efficiency.
Wi-Fi + App Control
Operate, schedule, and monitor remotely via the Madimack app.
Skimmer Mode Function
Automatically activates surface-skimming cycles to remove debris and keep your pool pristine.
Quiet Operation (~36 dB)
Advanced sound suppression ensures peaceful performance in any backyard setting.
Active Energy Monitor
Tracks real-time power usage and performance for smarter energy management.
Running Capacity 30%–100%
Fine-tune operation for any pool size with full inverter control and flexible set points.
4 Timers for Daily Operation
Customise up to four independent run cycles per day to match pool usage patterns.
Retrofit Ready
Direct replacement for existing pumps — no plumbing changes needed for common brands.
Compact Design
Fits neatly into tight equipment spaces for easy installation and maintenance access.
Loss of Prime & Low-Flow Protection
Automatically shuts down to prevent pump damage during low or no-flow conditions.
5-Year Replacement Warranty
Industry-leading coverage offering long-term reliability and complete peace of min
Key Features
- Full-inverter InverMAC DC brushless motor for efficient variable speed operation
- 6-Star energy-rated performance for maximum savings and sustainability
- Noise down to 35.4 dB at 30% speed – ideal for residential environments
- Wi-Fi connectivity with app-based remote scheduling and control
- Skimmer/Boost Mode for enhanced surface cleaning cycles
- Energy-efficient operation, reducing consumption by up to 80%
- Retrofits Astral Pool CTX, E, FX, and XP-Series pumps – no re-plumbing required
- Compact design fits easily in tight equipment spaces
- Digital display with touch controls for speed and timer settings
- Self-priming and dry-run protection for safe, reliable use
- 40/50 mm unions for easy plumbing compatibility
- Suitable for saltwater pools up to 3,500 ppm
- 5-year residential warranty / 2-year commercial warranty
Technical Specifications
| Model | InverFlow Plus 1HP | InverFlow Plus 1.5HP | InverFlow Plus 2HP |
|---|---|---|---|
| Power | |||
| Voltage Range | 220–240V 50/60Hz | ||
| Total Horse Power (THP) | 1.0 | 1.5 | 2.0 |
| Input Power (kW) | 0.75 | 1.05 | 1.5 |
| Running Amps (A) | 3.5 | 4.6 | 6.5 |
| Flow Performance | |||
| Max Flow (Qmax) L/Min | 367 | 425 | 517 |
| Max Head (Hmax) – Metre | 16 | 18 | 20.5 |
| Flow @ 8 m Head (L/min) | 300 | 367 | 500 |
| Flow @ 10 m Head (L/min) | 233 | 300 | 467 |
| Physical Details | |||
| Dimensions L × W × H (mm) | 544 × 252 × 288 | ||
| Pipe Connections | 40/50 mm Unions | ||
| Noise Level (30 % Speed) | 35.4 | 35.4 | 36 |
| Noise Level (100 % Speed) | 51.4 | 54.9 | 57.5 |
| Environmental Conditions | |||
| Ambient Temperature | 25.5 °C – 40 °C | ||
| Water Temperature | 5 °C – 50 °C | ||
| Salt Level Tolerance | Up to 3,500 ppm | ||
* Specifications displayed refer to 230V supply and can vary with voltage fluctuations.
2 years warranty for product installed in commercial application
InverFlow Plus 1HP
InverFlow Plus 1.5HP
InverFlow Plus 2HP
When Efficiency Matters
Efficiency isn’t just about saving power — it’s about creating a pool that runs quietly, smoothly, and effortlessly, so you can simply enjoy it.
